Description
Rectangular flat glass rooflight supplied complete with a 150mm kerb.
The rectangular format runs daylight along a room rather than pooling it in one spot, which suits galley kitchens, hallways and side returns. The kerb is included, and the thermally broken aluminium frame keeps the detail slim and well insulated.
Key Features
- Kerb supplied with the unit, in insulated timber or vertical uPVC
- Long format that spreads daylight across the room
- Toughened outer and laminated inner panes for overhead safety
- Fixed, trickle vented, manually opening or electrically opening
- Thermally broken frame in anthracite grey or any standard RAL colour
Specifications
- Shape: Rectangular
- Internal sizes: 500x800mm, 500x1100mm, 800x1100mm, 900x1400mm and 900x1900mm
- Glazing: Double glazed, toughened outer pane with a laminated inner pane
- Cavity: Argon filled with a warm-edge spacer
- Frame: Thermally broken aluminium box section
- External frame colour: RAL 7016 anthracite grey, or any standard RAL colour
- Kerb: 150mm insulated timber sloping kerb or 150mm vertical uPVC kerb
- Ventilation: None, manual trickle vent, manual opening or electric opening
- Ud-value: 1.3 W/m²K, glass unit tested vertically
- Standard frit width: 84mm
- Recommended install pitch: 5° to 15° on the upstand
- Non-fragility: CWCT TN66/67 Class 3
- Air tightness: Class 4 at 300 Pa to BS 6375-1:2015 and BS EN 12207
- Wind loading: Class A3 to BS 6375-1:2015 and BS EN 12210
Applications
- Flat roof extensions and side returns
- Galley kitchens and open-plan spaces
- Hallways, landings and corridors
- Offices and commercial fit-outs
- New build and refurbishment projects
