Description
Manual rectangular access hatch for roof access.
This access hatch provides safe entry to and exit from a flat roof, making it a practical choice for routine maintenance as well as escape routes. It is supplied complete with its own vertical upstand, so the roof opening only needs to be formed and the unit dropped in.
Key Features
- Opens by hand with no power supply required
- Supplied as a complete cover, upstand and hatch mechanism
- Choice of a glazed cover for daylight or a solid insulated cover for privacy
- Tested for watertightness and impact resistance
- Wide size range to suit both escape and maintenance openings
Specifications
- Product type: Cover, upstand and access hatch mechanism supplied as one unit
- Shape: Rectangular or square
- Cover options: Solid insulated cover, double-skin or triple-skin polycarbonate
- Operation: Manual, opening for access and for ventilation
- Upstand: Vertical, 150mm high
- Thermal transmittance: 2.68 W/m²K with double-skin polycarbonate, 1.78 W/m²K with triple-skin polycarbonate and 0.80 W/m²K with a 40mm solid insulated cover; the uPVC upstand itself achieves 1.00 W/m²K at 150mm vertical, 0.90 W/m²K at 150mm splayed and 1.00 W/m²K at 300mm splayed
- Sound reduction: 28 dB
- Fire performance to EN 13501-1: B-s3, d0 internally and BROOF (t4) externally
- Service temperature range: −50°C to +120°C
- Testing: Passes watertightness to EN 1873, 1200 J impact to EN 1873 and Class B to ACR(M)001:2005
- Internal sizes: 400 x 700mm, 400 x 1000mm, 500 x 800mm, 500 x 1100mm, 600 x 1200mm, 700 x 1300mm, 700 x 1600mm and 800 x 1300mm
Applications
- Roof access for maintenance
- Emergency escape routes
- Access to flat roofs
- Installation in residential buildings
